Gathering information about pharmaceuticals is difficult. There are multiple government-based sources of information, that sometimes contain mistakes, may overload and fail and generally can’t provide a good user experience for people who rely on that information. PharmPortal gathers the information from multiple services, verifies it, makes corrections and provides users with a convenient UI and API for integrations.

The goal

The first goal was to collect data from government’s online resources, normalising it, saving to the database and apply updates from next parsings. This was meant to be used internally within the company, but later it appeared that this information can also be useful for other businesses. The first concept was developed and launched, but with the desire to add new services it turned out that the current architecture was not suitable for expanding. Therefore, the next goal was to reinvent the architecture both for the backend and the frontend and release the second version of the portal.

My role

Initially I started working on the project as the lead frontend developer with 2 other developers under my management. The first version was successfully released and soon after I was offered to work on the second version. At that time I have founded my own team, called Atamore and continued working as the lead developer, supervising and teaching 2 developers of my own team. However, in spite of the client being a pharmaceutical company, the company wanted to created their own IT department, that would later continue the development and support of the project. We have decided that it would be best to integrate new developer from the client’s side into our team and work as one unit, but allowing new people to learn the codebase and later take the lead of the project. At that time I was managing 4 developers and also taking part in designing the system and the UI. After a few years of collaboration, the project was finally delegated entirely in the hands of the company’s employees, which for me as a great success, as we managed to help the client to become an IT company.

Engagements table

Technologies

I will focus on describing the architecture of the second version of the project, as the first version was mainly done as a proof-of-concept and didn’t require complicated solutions.

The backbone of the frontend is React.js, as it became almost a standard for the frontend development. But as SEO is one of the major requirements of the project, React is used along with Server-Side Rendering. The project is split on multiple services, each developed independently from each other, but sharing the core codebase, which defines and initialises the stack and also a UI library, which was created from scratch.

The UI library is created with Storybook, which is used for testing out the components and as a documentation for developers. Styled-components is used for styling and theming, as it is important to base all the components on the same color scheme and typography presets. But unfortunately the UI library is not typed, as the initial attempt to use Flow has failed and typescript was not yet stable enough to perform a second attempt to implement static typing. The final set of components is then packaged and published into the private NPM repository, from where it is installed to other projects. In combination with splitting the library into ESM and CJS builds we were able to achieve JS bundles that include only the components used.

Another major part is the API Gateway, also known as a Backend for frontend. It was needed because the Backend was split into multiple microservices, but in the majority of cases the data from one microservice needed to be enriched with information from another. As a solution we created a BFF service with Node.js, that was aggregating and enriching data and providing export to excel functionality based on queues and shared table schema. That schema was needed to mirror the representation of the data table on the frontend and its’ state in the export, as the table’s view can be customised by the user.

The final stack looked like this:

• React.js with Server-Side Rendering
• Redux for state management
• Styled-components for styling and theming
• UI components library with Storybook as a NPM package
• Node.js BFF built with Adonis.js
• RabbitMQ for file export queues

Findings form

Result

The project was successfully released both in its first and second iteration, which contains multiple public and private services. I’ve helped the company to hire and integrate their own developers, leading and teaching with along the way. And after several years of work the project was fully returned for further development to the client.
